您的位置：首页 > 产品中心 > 2MAG cuvetteMIXdrive 1 miniaturized magnetic stirrer cuvettes, Use with control unit
2MAG cuvetteMIXdrive 1 miniaturized magnetic stirrer cuvettes, Use with control unit
基本信息
| NACRES | NB.72 |
| General description【一般描述】 | Miniaturized, wear-free magnetic stirrer with 1 stirring position for cuvettes, optimized for stirring volume up to 25 ml, ideal size for system integration e.g. in photometer. 1 stirring position, 100 percent maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept for reliable mixing of solutions, jerk-free stirring even at low speeds. Fully encapsulated and hermetically sealed polyurethane housing, IP68, water-, dust- and germproof. |
| Features and Benefits【特点和优势】 | Extremely robust construction and performance, easy to clean and maximum resistance, submersible in water- or oil baths, suitable for the use in CO2-incubators and ovens. |
| Other Notes【其他说明】 | Please order control unit separately! |
产品性质
| AC/DC input | 48 V |
| material【物料】 | housing (polyurethane) plate (Polyurethane) |
| feature【特点】 | positions 1 10 W Stirring Power |
| packaging【包装】 | pack of 1 ea |
| manufacturer/tradename | 2mag 40400 |
| parameter【参数】 | ≤50 ℃ temp. limit (in water) -10-50 ℃ temp. limit (in air) |
| W × D × H【宽度 × 直径 × 高度】 | 13 mm × 13 mm × 6 mm |
| capacity【容量】 | 1-25 mL , per stirrer position |
| plate size × W × L | × 12 mm × 12 mm |
| weight【重量】 | 0.1 kg |
