您的位置：首页 > 产品中心 > HPTLC Silica gel 60 Multiformat pre-scored to 5 x 5 cm
HPTLC Silica gel 60 Multiformat pre-scored to 5 x 5 cm
| 产品编号： | 4157375 |
| 规格： | pkg of 100 plates, plate L × W 10 cm × 10 cm, glass support |
| 包装规格： | 100 UNITS |
| 产品类别： | 进口试剂 |
| 品牌： | Supelco |
| 优惠价： | 立即咨询 |
产品性质
| material【物料】 | glass support silica gel 60 matrix |
| Quality Level【质量水平】 | 100 |
| feature【特点】 | binder Organic Polymer fluorescent indicator: no |
| packaging【包装】 | pkg of 100 plates |
| technique(s) | thin layer chromatography (TLC): suitable |
| layer thickness【层厚度】 | 200 μm |
| plate L × W【板长度 × 宽度】 | 10 cm × 10 cm |
| Particle size【粒径】 | 5-6 μm |
| pore size【孔径】 | 60 Å medium pore diameter |
| storage temp.【储存温度】 | 2-30℃ |
基本信息
| General description【一般描述】 | 100 Glass plates 10 x 10 cm HPTLC plates deliver fast and quantitative analysis of complex samples for manual or automated use. Our HPTLC silica plates work three times faster than conventional TLC plates – and they are more sensitive. The particle sizes range in HPTLC is between 4-8 µm, which creates a smoother surface and a higher separation power than TLC plates. |
| Linkage【联系】 | Replaces: 5644-5; 5644 |
| Analysis Note【分析说明】 | Specific surface area (according to BET; 5-Pt. measurement): 480 - 540 m²/g Pore volume (N₂-isotherm): 0.74 - 0.84 ml/g d 50 (laser diffraction, size distribution): 5 - 7 µm Layer thickness: 150 - 200 µm Deviation of layer thickness per plate: ≤ 35 µm Chromatographic testing: colour test hRf-values - bleu vif organol, colour test, lipophile: 17 - 22 - Ceres Black G, colour test, lipophile: 38 - 43 - ceres Violet brn, colour test, lipophile: 58 - 64 separation number (colourtest, lipophile): ≥ 10.0 Typical value determined on a conditioned plate Eluent: toluene |
